1/0-4 MC Cable

Four-Conductor 1/0 AWG Metal Clad Cable for High-Capacity Three-Phase + Neutral Power Distribution

  • Conductor Size 1/0 AWG stranded copper
  • Construction Four conductors (black, red, blue, white) + green or bare ground
  • Armor Interlocked aluminum armor
  • Voltage Rating 600V
  • Insulation THHN/THWN-2 insulation
  • Standards UL Listed, NEC Article 330 compliant
  • Temperature Rating 90°C (dry locations)

Conatact us

Name

Email

Phone

Message

Congratulations. Your message has been sent successfully.
Error, please retry. Your message has not been sent.

1/0-4 MC Cable – Four-Conductor 1/0 AWG Metal Clad Cable for High-Capacity Three-Phase + Neutral Power Distribution

1/0-4 MC Cable features four color-coded 1/0 AWG copper conductors and a ground wire, all enclosed in a heavy-duty aluminum interlocked armor. It is designed for large-scale electrical infrastructure requiring high ampacity and a separate neutral conductor, such as commercial and industrial power distribution systems.

Typical Applications of 1/0-4 MC Cable

  • Main power feeders in commercial buildings
  • Industrial equipment supply circuits
  • High-current panel board distribution
  • Large-scale lighting and HVAC systems
  • Utility rooms and switchgear installations

Advantages of Using 1/0-4 MC Cable

  • High Current Capacity: Suitable for demanding power loads
  • Integrated Armor: Eliminates the need for additional conduit
  • Simplified Installation: Reduced labor and faster deployment
  • Versatile Use: Ideal for feeders with neutral and 3-phase loads

FAQs

Q: What’s the ampacity of 1/0 MC Cable?
A: Typically around 150–170 amps depending on conditions. Always refer to NEC ampacity charts for specifics.

Q: Can this cable be used in wet locations?
A: Not unless specified with additional jacketing (e.g., PVC-jacketed MC-HL type).

Q: Does this cable meet hospital grade or specialty codes?
A: Standard 1/0-4 MC Cable may not. Check with our team for hospital-grade MC options.
